Energetika-VDS ST Programmable Temperature Regulator with External Probe

Programmable external-probe temperature regulator, -40 to +125 °C range, ten memory registers plus weekend register, RTC scheduling, and 2-year lithium backup. 10 A or 20 A relay variants.

Request a Quote Talk to engineering Download spec sheet

Overview

ST is the external-probe sibling of the DT regulator. Same RTC and ten-register programmable schedule, with a wide -40 to +125 °C probe range for ovens, boilers, refrigeration coils, and process tanks. Two-line LCD shows probe temperature alongside the active set-point. 10 A or 20 A relay variants share one board.

Key features

External probe -40 to +125 °C
Ten programmable time / temperature set-points + weekend register
Real-time clock with ±1 s/day accuracy
3.6 V lithium backup retains schedule for 2 years

Variants

ST-10

10 A relay variant.

Relay rating: 10 A, 220 V AC, 50 Hz
Order code: ST-10

ST-20

20 A relay variant.

Relay rating: 20 A, 220 V AC, 50 Hz
Order code: ST-20

How it is used

Ovens, boilers, refrigeration coils, industrial process tanks, and any application where the controlled medium is at a temperature far outside the regulator enclosure. ST extends the programmable schedule logic of the DT to a -40 to +125 °C external probe.

How we build it

Single-board external-probe regulator built on our DDM Novastar line. Same line and process as the DT variant. The external probe is wired through a screw terminal on the PCB; probe harness is paired and shipped as a kit with the unit.

Assembled on our in-house Novastar SMT line: SPR-45, LS60, GF-120HT.

Optical inspection and test

AOI inspects placement, RTC crystal alignment, LCD seating, relay polarity, and probe connector. Functional check at the line: probe linearity across -40 / 25 / +125 °C against a reference thermometer, relay switch at set-point, RTC drift, backup-retention behaviour.

Design specifications

Mechanical

Wall-mount enclosure 96.4 × 142.4 × 44.7 mm. External probe on quick-connect harness.

Electrical

220 V AC at 50 Hz. Relay rating per variant: ST-10 = 10 A, ST-20 = 20 A at 220 V AC.

Environmental

Probe range -40 to +125 °C, ±0.5 °C high-temperature converter accuracy at 25 °C.

Communication

No external comms. RTC ±1 s/day. 3.6 V lithium backup retains schedule for 2 years without mains.

Specifications

Nominal voltage: 220 V AC, 50 Hz
Temperature measurement range: -40 to +125 °C (external probe)
High temperature converter accuracy at 25 °C: 0.5 °C max
Programmable memory registers: 10 weekday + 1 weekend
RTC accuracy: ±1 s/day
Backup supply: 3.6 V lithium, 2 years
External dimensions: 96.4 × 142.4 × 44.7 mm
